Carbon Steel Weld Stud with 3 Projections On Top of Head

Material: Stainless steel, Carbon steel, Brass

Standard: Q 199&QC /T 599 (A) - 2013&IFI 148 (T3) - 2002 T3

Weld Stud with 3 Projections On Top of Head

This Projection Weld Screw features three precision weld projections located on the top of the head to allow for welding directly to (as opposed to through) the surface of the sheet material. The three projections are of equal height and mass and are positioned on the head, allowing for a robust weld connection while eliminating the need for drilled holes. These industrial fasteners are available from Juxin Fasteners in various materials, dimensions, and thread sizes (inch and metric).

Typical properties of this Projection Weld Screw:

Material

C1010 High-Welding Quality, Low Carbon Steel (plain finish unless otherwise specified)

18-8 Stainless Steel (passivated finish)

Threads

Inch: Unified Standard Class 2A ASME B 1.1-2003

Metric: ASME B 1.13M-2005

Available thread sizes

Inch Metric

#6-32 M3.5 x 0.6

#8-32 M4 x 0.7

#10-24 M5 x 0.8

#10-32 M6 x 1.0

1/4-20 M8 x 1.25

5/16-18 M10 x 1.5

3/8-16

Note: A variety of dimensional characteristics also available (lengths, diameters, etc.)

Application notes

This weld screw allows for welding directly to the surface of the sheet material. Three symmetrical weld projections located on top of the head allow for a robust weld that will not disfigure the exterior surface of the sheet material. The screw head will not protrude through the surface of the sheet; therefore, a clean, smooth surface appearance is maintained. This weld screw is an ideal choice for blind locations since it can be easily pre-attached.

For applications that require a robust weld screw that can be applied directly to a sheet surface without leaving a protruding head on the opposite side of the sheet, this particular weld screw is an excellent choice. It is also an ideal choice for designs incorporating one or more blind attachment locations.

Juxin Fasteners has 22 years of experience in the industrial fastener business. We carry a full suite of industrial fastener products and pride ourselves on staying abreast of all industry trends and developments.
