Q809 Sleeve type three pass joint body

Material:Stainless steel SUS304.316,Carbon steel ,Brass

Standard:Q809


Share:

Product Specification

①, No. Example: DW=14, zinc-plated, rainbow-colored passivated ferrule-type taper-threaded right-angle fitting body No. Q808B14. there should be no cracks, pores, burrs, sharp edges, rust spots, and other defects affecting the use of the body.
Use of ferrule-type pipe fitting: ferrule type pipe fitting is suitable for piping systems with oil, gas, and water as a medium. Applicable pressure range: (G) 25Mpa, (J) 40Mpa.
Tube fitting features: Tube fitting has a series of advantages such as advanced structure, good performance, ease of use, no welding, no need to flare the piping, and so on. Therefore, ferrule fittings have been widely used in all kinds of mechanical hydraulic, and pneumatic system, but ferrule fittings ferrule manufacturing precision is higher, due to the complexity of the process, not sporadic or small batch manufacturing, need to be specialized production.


When the nut is tightened, the ferrule is pushed into the 24° taper hole under pressure. With it down and deformation, the ferrule and the connector body taper to form a spherical contact seal. At the same time, the ferrule is embedded in the outer wall of the tube, and a ring-shaped closed edge is pressed out on the outer wall, thus playing a reliable sealing role, and the middle part of the ferrule is slightly arched with a certain degree of elasticity, which is conducive to sealing and preventing the nut from loosening, and the end of the ferrule is also radially contracted to hold the tube. Tube fittings with metric fine threads or taper threads and machine connections, and to use sealing washers, when the medium pressure level recommended sealing washers (JB1002-77), high pressure recommended with a combination of sealing washers (JB982-77) or sealing washers (JB1002-77).


Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF, CAD, 101-102 Page See more product details.


Product Packaging

Packing: The inner packaging consists of polyfoam, while the outer layer is a carton. The carton sizes are 29*19*19.5 cm and 23.5*17.5*8 cm, respectively. The pallet dimensions are 215*100*90 cm, or they can be customized according to your requirements.


Product Pictures

Q809 Sleeve type three pass joint body
