Q679 Stainless steel Symmetrical Clip for Twin Pipes

Material:08,08F,Q235F
Can add polyethylene, vulcanized rubber coating, or vulcanized rubber sleeve in the clamping pipe part of the galvanized and passivated clamping piece according to the functional requirements, the vulcanized rubber should be added with black carbon and stabilizer.
The color is black and the thickness is 0.8mm~1.5mm.
Discoloration, deformation, and deterioration are not allowed;
Polyethylene coating or vulcanized rubber coating is not allowed to have cracks, burrs, scratches, depressions, bubbles, ripples, impurities, and rough and uneven surfaces;
The thickness of the polyethylene coating or vulcanized rubber coating shall be uniform.
①, No. Example:
1. D=10, galvanized, iridescent passivated symmetrical double pipe clamps No. Q67910.
2. D=10, plastic-coated symmetrical double tube clamps are numbered Q67910F4.

Stainless steel U-shaped card is made of stainless steel strip stamping, and the surface is smooth, and delicate, in terms of material there are 304 material, 304L material, 316 material, 316L material, that is, with austenitic stainless steel water pipes have these materials, different materials, in terms of corrosion resistance, hardness is different, but in general, in the natural environment applications have corrosion resistance, Resistant to rust features. Stainless steel U-shaped card specifications are suitable for DN15-DN65 pipeline installation, its thickness is 0.4, 0.6, and 0.8 thickness, of course, some of the thickness of 0.1, because of the stainless steel U-shaped card toughness, corrosion prevention, so even if the thickness is relatively thin, but for the fixed pipe is still possible, because, in the face of large pipeline installation, The pipe can be fixed with brackets and stainless steel U-shaped cards.

Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF， CAD, 89-90 Page See more product details.

Packing: The inner packaging consists of polyfoam, while the outer layer is a carton. The carton sizes are 29*19*19.5 cm and 23.5*17.5*8 cm, respectively. The pallet dimensions are 215*100*90 cm, or they can be customized according to your requirements.
