Q656 Expanding taper thread three-way joint&Flared Couplings - Male Branch Tee - Body

45° Flared Fittings for Copper and Brass Tubing.Temperature Range: -65° to 250° F
Tubing: Use with seamless brass and copper that meets ASTM B280.No sleeve is required to assemble these fittings, which makes for a faster, more convenient installation compared to 37° flared fittings. They require a nut (sold separately) for each tube end. Fittings are also known as refrigeration and SAE fittings. They are brass for good corrosion resistance.NPTF (Dryseal) threads are compatible with NPT threads. Copper tube size is the accepted designation of the copper tubing industry, not the actual tube OD.

Cleaned and Bagged 37° Flared Fittings for Stainless Steel Tubing.For Use With:

NPT Threads: Air, Hydraulic Fluid, Isopropyl Alcohol, Natural Gas, Phosphoric Acid, Water
UN/UNF (SAE Straight) Threads: Air, Isopropyl Alcohol, Water
Temperature Range:
NPT Threads: -420° to 1200° F
UN/UNF (SAE Straight) Threads: -15° to 400° F
Tubing: Use with seamless or welded 304 or 316 stainless steel that meets ASTM A213, ASTM A249, or ASTM A269
Specifications Met: SAE J514, ISO 8434
Individually bagged to prevent contamination, these fittings are suitable for applications that require a high level of cleanliness. Also known as JIC (Joint Industrial Council) fittings, they provide a tight metal-to-metal seal on tubing that is flared to 37°. They are 316 stainless steel for excellent corrosion resistance. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately and are not cleaned and bagged.
UN/UNF (SAE Straight) male threads have a gasket to protect against leaks. They are also known as O-ring boss threads.

Size Can also be According to the Customer's requirement please check the detailed specification sheet details PDF， CAD, 107-108 Page See more product details.

Packing: The inner packaging consists of polyfoam, while the outer layer is a carton. The carton sizes are 29*19*19.5 cm and 23.5*17.5*8 cm, respectively. The pallet dimensions are 215*100*90 cm, or they can be customized according to your requirements.
