Self-clinching Fasteners for Sheet Metal

Grounding Standoffs – Types JX-SOAG, JX-SOSG

Material:

Stainless Steel: SUS302, SUS303, SUS316, SUS410, SUS420, SUS430, etc.

Share:

Product Specification

Size Can also be According to the Customer's requirement and please check the detailed specification sheet details PDF, CAD, 43-44Page See more product details.


Used to ground P.C. boards to steel or aluminum chassis. Annular projecting teeth eliminate the need for serrated or star washers to make good electrical contact with the circuit foll. Thread sizes #4,#6, and M3, M4.These standoffs, which use the proven self-clinching design, install with a squeeze in properly sized round holes - and become permanently mounted on the thin sheet. Types JX-SOAG and JX-SOSG grounding standoffs are designed for clinching into steel or aluminum chassis while the “gripping teeth” on the opposite end of the standoff firmly contact mating PC board. If you require a standoff which we do not offer in this bulletin, please contact us. We will be happy to work with you to satisfy your special need. For special lengths greater than .500”, Types JX-SOSG and JX-SOAG are blindly threaded.

Product Packaging

E. Packing: Inner is Poly foam, out is carton. Then pallet. Carton size: 29*19*19.5CM and 23.5*17.5*8, CM and pallet size is: 215*100*90CM, or as your requirement.

Product Pictures

Grounding Standoffs – Types JX-SOAG, JX-SOSG


Grounding Standoffs – Types JX-SOAG, JX-SOSG
