What is the difference between an Inverted External Retaining Ring and Retainers For Shafts?

Oct. 17, 2023

What are the Inverted External Retaining Ring and Retainers For Shafts?

As an indispensable part of mechanical manufacturing, the stop ring has different types in different robotic designs. The Inverted External Retaining Ring and Retainers For Shafts commonly use retaining rings.

1. Inverted External Retaining Ring: This ring is used in reverse operation to prevent axial runout or reverse rotation.

2. Shaft retaining ring: usually installed on the shaft, used to limit the shaft or the parts on the shaft in the axial position to prevent it from loosening or offset.

The main difference between the reverse shaft retaining ring and the shaft retaining ring

The difference between the Inverted External Retaining Ring and Retainers For Shafts is the different application scenarios. The reverse shaft retaining ring is mainly used for the reverse operation scene, and the shaft retaining ring is primarily used for the general axial positioning work. Specifically, reverse shaft retainers are commonly used in specific mechanical devices that require orientation or position control in the case of reverse rotation. They can effectively limit the shaft or parts on the shaft in the axial upwards position, preventing it from jumping or turning during high-speed reverse operation. In contrast, shaft retainers are usually used for axial position control or positioning work. The retaining ring installed on the shaft prevents the shaft or the parts from loosening or deviating, thus ensuring the stability and efficiency of the shaft.

What is the difference between an Inverted External Retaining Ring and Retainers For Shafts?cid=57What is the difference between an Inverted External Retaining Ring and Retainers For Shafts?cid=57

The Retaining and advantages of different stopper application scenarios

According to different application scenarios, the reverse shaft retaining ring and the shaft retaining ring have unique characteristics and advantages. Taking the reverse shaft retaining ring as an example, it can effectively prevent the axial run out and rotation during reverse operation to ensure the working stability and reliability of mechanical equipment. At the same time, the reverse shaft retaining ring also has the advantages of simple installation and compact structure.

The shaft retaining ring mainly has the function of axial position control and positioning. Its advantage is that it is more accurate and stable, which can ensure that the shaft position or the parts on the shaft do not deviate from the axial direction to ensure the accuracy and stability of the mechanical equipment in the working process. The retainer for the reverse shaft and the retainer for the shaft are standard parts of mechanical design. They have unique characteristics and advantages in different application scenarios, and how to choose depends on specific needs and requirements.

If you are looking for high-quality fastener screws & all kinds of washers or technical support for structural design, please get in touch with me. Thanks. Email: adelajonly@gmail.com Website: www.juxinfasteners.com
