Hexagonal blind rivet nut solution

Hexagonal blind rivet nut features

1. Can have high torsional strength, suitable for occasions that need to withstand strong force;

2. The end only has an opening, Internal threads, that can catch the plate and screw in to form a connection;

3. Can be used in the assembly of various structures and is one of the widely used fasteners;

4. Rivet nuts can avoid the disadvantages of using traditional bolts and nuts, effectively improving production efficiency;

5. It is more suitable for the environment of repeated disassembly and installation.

Heavy Duty Twist-Resistant Rivet Nuts: A hex-shaped body provides the highest twist resistance of any rivet nut. They're zinc-plated for mild corrosion resistance. Install in a punched hole with a lever-style or power-driven rivet nut tool. The tool collapses the nut, creating a backside flange that holds the nut to the material. Length is measured from under the flange. Installed length is the maximum length of the barrel when installed.

Hexagonal rivet nut use precautions

1. Please pay attention to different materials and different length specifications when selecting rivet nuts;

2. Rivet nuts are in the screw structure; the specific application depends on the particular situation;

3. When installing the rivet nut, please use the sketch to determine the installation position before screwing in the nut, and be careful not to tighten it too much;

4. After screwing in the rivet nut, recheck the tightness to ensure safety and reduce possible problems.

Flange-Sealing Rivet Nuts: The PVC foam seal under the flange keeps liquids and gasses from leaking between the nut and the surrounding material. These rivet nuts have a ribbed body to hold them in place when tightening a screw. The body is aluminum and mildly corrosion-resistant. Install in a drilled hole using a rivet nut tool. The tool collapses the nut, creating a backside flange that holds the nut to the material. Length is measured from under the flange. Installed length is the maximum length of the barrel when installed.

A hexagonal closed-end rivet nut is a fastener suitable for fastening. Connecting in a variety of environments, with good seismic performance and high torsional strength, to a certain extent, to solve the problem of plate fixing, the use of precautions and the corresponding specifications of choice in production, engineering, or daily life can effectively improve the stability and safety of the material.

The complete hexagonal closed-end riveted nut includes a body provided with a blind hole, which is equipped with a ring-like fixing part at the opening. The blind hole consists of a smooth section and a threaded section, and the aperture diameter of the soft section is larger than the aperture diameter of the threaded section. Characterized by the edge of the fixed part toward the end face of the body extends upward to form a protrusion, the protrusion and the fixed part of the connection of the arc surface, the protrusion and the side wall of the body constitute a cushioning member mounting groove, the cushioning member mounting groove is provided with a rubber ring, and the radius of the arc surface and the radius of the rubber ring are equal. The rubber ring height is higher than the height of the protrusion, and the rubber ring and the body of the gap between the fit.

The complete hexagonal closed-end riveted nut in the fixed part toward the surface of the external object is integrally provided with a protrusion, where the rubber ring can form a buffer between the fixed part and the external object to prevent the external force from being too large will result in the selected part. The external object between the relative depression and damage to the parts of the situation occurs to ensure that the average service life of the riveted nut and the structure layout is reasonable.

All-hexagonal closed-end riveted nut in the use of the process without additional installation tools to solve the difficulty of using a rivet gun in a narrow space for riveting technical problems, and can be delicious to ensure the quality of riveting to improve the reliability of the riveting and sealing.
