Features and applications of stainless steel self-tapping screws

Features and applications of stainless steel self-tapping screws

Stainless steel self-tapping screws are a kind of standard fastener whose primary function is to connect two or more parts firmly. Compared with standard screws, stainless steel self-tapping screws have better corrosion and oxidation resistance, so they are widely used in marine, chemical, petroleum, food and pharmaceutical fields.

Stainless steel self-tapping screws are usually manufactured from stainless steel (e.g., 304, 316, etc.), which is characterized by high strength, good corrosion resistance, and long life. At the same time, the head of stainless steel self-tapping screws is usually hexagonal or rounded to facilitate the use of wrenches or drivers for tightening.

The use of stainless steel self-tapping screws is very simple; you need to align the tip of the self-tapping screw with the part to be connected and then rotate it with force. The tip of the self-tapping screw can be used to punch a hole directly into the part, creating a thread that allows the thread to be securely fastened into the part.

18-8 Stainless Steel Phillips Rounded Head Screws for Sheet Metal:18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. They penetrate 0.025" and thinner sheet metal. Length is measured from under the head.

Black-oxide stainless steel screws have a dark surface color.

Super-Corrosion-Resistant 316 Stainless Steel Phillips Rounded Head Screws for Sheet Metal: More corrosion resistant than 18-8 stainless steel screws, these have excellent resistance to chemicals and salt water and may be mildly magnetic. They penetrate 0.025" and thinner sheet metal. Length is measured from under the head.

18-8 Stainless Steel Extra-Wide Rounded Head Screws for Sheet Metal:18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. They have a wider head than standard rounded head screws to distribute holding pressure and reduce the risk of crushing thin metal. They penetrate 0.025" and thinner sheet metal. Length is measured from under the head.

Amper-Resistant Torx Rounded Head Screws for Sheet Metal: A tamper-resistant Torx driver is required for installation and removal. Also known as pin-in-Torx, these screws allow you to apply extra force with less slippage or damage to the recess. Made from 18-8 stainless steel, they are chemical resistant and may be mildly magnetic. They penetrate 0.025" and thinner sheet metal. Length is measured from under the head.

Rounded Head Screws with Washer for Sheet Metal: A free-rotating, permanently attached washer distributes holding pressure over a wider area than a flange and remains stationary to prevent scratching the material surface as you tighten the screw, They penetrate 0.025" and thinner sheet metal. Length is measured from the edge of the head. Head height includes the washer.

Black phosphate and black-oxide steel screws are mildly corrosion-resistant in dry environments.

Chrome-plated steel screws have a bright and attractive finish. They're corrosion-resistant in wet environments.

18-8 Stainless Steel Phillips Flat Head Screws for Sheet Metal:18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. They're beveled under the head for use in countersunk holes. Screws penetrate 0.025" and thinner sheet metal. Length is measured from the top of the head. Undercut screws allow for more threading.

18-8 Stainless Steel Flanged Hex Head Screws for Sheet Metal:18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. They have a hex head for a secure grip with a wrench and a flange to reduce the risk of crushing thin metal. Screws penetrate 0.025" and thinner sheet metal. Length is measured from under the flange. Head height includes the flange.

18-8 Stainless Steel Rounded Head Blunt Screws for Sheet Metal:18-8 stainless steel screws have good chemical resistance and may be mildly magnetic. Often referred to as Type B thread-forming screws, they require a drilled hole and are typically used in 0.050"-0.200" material. Length is measured from under the head.

Features of stainless steel self-tapping screws

Stainless steel self-tapping screws with a curved triangular cross-section of the thread for the ordinary thread, the thread surface also has a high degree of hardness, so in the connection, the screw can also be connected in the connection of the threaded bottom hole tapped out of the internal threads, to form a connection. This screw is characterized by low screwing torque and high locking performance, is better than ordinary self-tapping screws, has better working performance, and can be used instead of machine screws.

1. Wallboard self-tapping screws are used for the connection between the gypsum wallboard and metal keel. Its thread is a double-head thread; the thread surface also has a high hardness (≥ HRC53) and can not make a prefabricated hole under the conditions of fast screwing into the keel to form a connection.

2. Stainless steel self-drilling self-tapping screws and ordinary self-tapping screws is different from ordinary self-tapping screws in the connection, subject to drilling (drilling threaded holes) and tapping (including fastening connections) two processes, and self-drilling self-tapping screws in the connection, the drilling and tapping of the two processes are combined to be completed at once. It first drills holes with the drill in front of the screw and then taps with the screw (including fastening connections), saving construction time and improving construction efficiency.

3. Pan head and hexagonal head stainless steel tapping screws are suitable for the occasions where the drill bit is allowed to be exposed; hexagonal head tapping screws can be larger than the pan head tapping screws with enormous torque. The countersunk head and hexagonal flower-shaped self-tapping screws for nail head are not allowed to reveal the occasion; hexagonal flower-shaped self-tapping screws can be more than the passive head self-tapping screws with a more significant moment; semi-sedentary head self-tapping screws for nail head allowed to be slightly exposed to the occasion. Self-tapping screws when mounting and dismantling, slotted self-tapping screws need to use screw screws, cross slot self-tapping screws need to use cross-shaped screw screws, hexagonal flower-shaped self-tapping screws need to use hexagonal flower-shaped wrenches, hexagonal head self-tapping screws need to be used with dull wrenches, wrenches, socket wrenches, or live wrenches.

Stainless steel self-tapping screws have excellent corrosion resistance and high strength, so they are widely used in aviation, shipping, chemical industry, electric power, communications, construction and other fields.Stainless steel self-tapping screws, in addition to general screws, there also have critical anti-rust characteristics and long-term use, not easy to rust. In addition, stainless steel self-tapping screws have the function of general screws but also have essential anti-rust characteristics; long-term use is not easy to rust; in addition, stainless steel screws have a clean appearance, easy to clean, in line with the requirements of health. In addition, stainless steel self-tapping screws have lightweight, have a long service life, and other characteristics.

Application scope of stainless steel self-tapping screws

Stainless steel self-tapping screws are an essential fastener, widely used in construction, transportation, light industry, electronics, communications, and other industries. Its scope of application includes the following aspects:

1. Tthe need for long-term use and maintenance of equipment, such as food machinery and medical equipment.

2. The outdoor environment is harsh, and it is easy to rust in rivers, marine engineering, city roads, etc.

3. Places with high gloss and strong corrosion resistance, such as hospitals, electronic factories, etc.

4. Places with high purity requirements, such as medical appliances, power equipment, etc.

Selection tips and precautions for stainless steel self-tapping screws

1. Select stainless steel self-tapping screws with corresponding material according to different occasions of use.

2. When buying stainless steel self-tapping screws, pay attention to whether the size and pitch of the screws and other parameters meet the requirements to ensure the quality of installation.

3. When using stainless steel self-tapping screws, pay attention to the moderate strength, do not over-tighten so as not to cause loosening or damage.

4. Regularly check the use and tightness of stainless steel self-tapping screws and timely replacement or adjustment.

5. Stainless steel self-tapping screws are mainly for the whole structure; it is not recommended to dismantle them by yourself so as not to bring unnecessary safety hazards.

In short, stainless steel self-tapping screws have excellent corrosion resistance and high strength and are widely used in various fields; the correct use and purchase of stainless steel self-tapping screws can effectively increase the service life of the product and reduce safety hazards.

In short, stainless steel self-tapping screws are a convenient fastener with good corrosion resistance, strong oxidation resistance, long life, and other advantages. When using them, you must choose the correct specification and model according to the specific situation to ensure they can be firmly fixed in the components.For high-quality 18-8 Stainless Steel Phillips Rounded Head Screws for Sheet Metal and professional technical support, don't hesitate to contact us at adelajonly@gmail.com or visit our website at: https://www.juxinfasteners.com.
